Reliable HEDP Manufacturer Offering Corrosion & Scale Inhibitor Solutions

As a leading HEDP manufacturer, we provide HEDP Chemical – 1-Hydroxy Ethylidene-1,1-Diphosphonic Acid, a highly effective scale and corrosion inhibitor commonly used in water treatment applications. It is known for its strong chelating ability with metal ions like calcium and iron.

Process Manufacturing of HEDP

The manufacturing process of 1-Hydroxyethane-1,1-diphosphonic acid (HEDP), also known as Etidronic Acid, involves a controlled reaction between phosphorus trichloride (PCl₃), acetic acid, and phosphorous acid under specific conditions. Initially, acetic acid and phosphorous acid are mixed, and phosphorus trichloride is added slowly while maintaining the temperature and pH to prevent unwanted side reactions. This results in the formation of HEDP as the primary product. The reaction mixture is then subjected to purification processes like distillation and crystallization to obtain a high-purity acid. The final product is either presented as a colorless liquid or white crystalline powder, depending on the concentration and intended application. This process ensures that the resulting HEDP maintains strong chelating properties, excellent stability, and effective scale and corrosion inhibition, making it ideal for water treatment, detergents, and industrial cleaning applications.



Specification

Active acid : 60% min

Specific gravity at 25oc : 1.44±0.01

pH of solution : Less than 2

Iron content as Fe : 20 ppm max.

Chloride as Cl% : 0.1% max.

Sequestering value at pH11 : Min 520 mg of CaCo3 / gm. of product.

Advantages of Using HEDP Chemical

1. Excellent Chelating Agent

1-Hydroxyethane-1,1-diphosphonic Acid effectively binds with metal ions like calcium, magnesium, and iron, helping to prevent scale buildup in water systems.

2. Superior Scale and Corrosion Inhibitor

HEDP Etidronic Acid offers long-lasting protection against scaling and corrosion, making it ideal for use in cooling towers, boilers, and pipelines.

3. Stable Across Wide pH Range

1-Hydroxy Ethylidene-1, 1-Diphosphonic Acid remains effective in both acidic and alkaline environments, allowing it to be used in diverse industrial applications.

4. High Thermal Stability

HEDP Chemical can withstand high temperatures without decomposing, making it suitable for use in high-pressure systems.

5. Good Compatibility with Other Chemicals

HEDP – 1-Hydroxyethane-1,1-diphosphonic Acid works well with other water treatment chemicals, enhancing its versatility in formulation.

6. Biodegradable and Environmentally Safe

HEDP Chemical/Etidronic Acid has low toxicity and is biodegradable, making it a safer choice for long-term environmental use.

Application of HEDP Etidronic Acid

1. Water Treatment Industry

HEDP Chemical is extensively used in industrial water treatment systems to prevent scale and corrosion. It stabilizes metal ions in water, ensuring smooth operation of boilers, cooling towers, and pipelines, thereby extending equipment life and maintaining efficiency.

2. Oil & Gas Industry

In oilfields, 1-Hydroxy Ethylidene-1, 1-Diphosphonic Acid is used to control scale formation in drilling fluids and injection water systems. Its strong chelating ability helps reduce mineral deposits, improving fluid flow and protecting valuable extraction equipment from damage.

3. Detergent Manufacturing

HEDP Etidronic Acid enhances the effectiveness of both household and industrial detergents. It softens hard water by binding with calcium and magnesium ions, improves cleaning efficiency, and prevents mineral deposits on surfaces and fabrics.

4. Paper & Pulp Industry

HEDP Chemical is used to manage scaling in paper processing equipment and maintain system cleanliness. It also helps preserve paper quality by controlling metal ion interference during bleaching and production processes.

5. Cosmetic & Personal Care Industry

In cosmetics, 1-Hydroxyethane-1,1-diphosphonic Acid serves as a chelating and stabilizing agent in formulations like shampoos, creams, and lotions. It enhances product stability by binding metal ions that could cause degradation or discoloration, thereby extending shelf life.

Why Textile Industry’s First Choice is HEDP Chemical for Dyeing & Finishing

HEDP/Etidronic acid (1-Hydroxyethylidene-1,1-Diphosphonic Acid) is the Favored Agent in the textile industry for dyeing and finishing processes due to its excellent chelating and anti-corrosion properties. It effectively controls metal ions like calcium and magnesium, which can interfere with dye uptake, ensuring vibrant and uniform colors. HEDP’s outstanding stability at high temperatures and various pH levels makes it ideal for harsh textile processing conditions. Additionally, it prevents scale formation and protects machinery from corrosion, enhancing Process optimization. Its compatibility with detergents and softening agents further improves fabric quality, making HEDP the first choice for textile manufacturers worldwide.

Benefits of HEDP in Textile Sector

1. Prevents Scale Formation in Dyeing Machines

1-Hydroxyethane-1,1-diphosphonic Acid helps prevent calcium and magnesium scale deposits in dyeing and finishing equipment, ensuring smooth operation and reducing maintenance needs.

2. Improves Dyeing Quality

By chelating metal ions that can interfere with dyes, HEDP Etidronic Acid ensures even and consistent dye uptake, improving fabric color uniformity and brightness.

3. Enhances Cleaning Efficiency

HEDP Chemical boosts the effectiveness of cleaning agents used in textile processing by softening hard water, leading to better fabric washing and reduced chemical usage.

4. Protects Equipment from Corrosion

1-Hydroxy Ethylidene-1, 1-Diphosphonic Acid forms a protective layer on metal surfaces, protecting machinery and pipelines from corrosion caused by water and chemicals used in processing.

5. Stable Under High Temperature and pH

HEDP Etidronic Acid remains effective under the high-temperature and variable pH conditions typical of textile operations, ensuring reliable performance throughout different stages of fabric processing.



Chemical Synonyms for HEDP:

1) Etidronic acid

2) 1-Hydroxyethylidene-1,1-diphosphonic acid

3) Hydroxyethane diphosphonic acid

4) HEDP acid

5) Hydroxyethylidene diphosphonate

6) HEDPA

7) Etidronate

Contact us; we take pride in being a leading HEDP or Etidronic Acid supplier. Reach out to our expert team to get a quote, request samples, or discuss custom formulation needs.



FAQs

1. What is HEDP and what are its primary uses?

HEDP/1-Hydroxyethane-1,1-diphosphonic Acid/Etidronic Acid is a strong chelating agent used mainly as a scale and corrosion inhibitor in water treatment, detergents, and industrial cleaning applications.

2. How is HEDP manufactured?

HEDP Chemical is produced through a controlled reaction of phosphorus trichloride, acetic acid, and phosphorous acid, followed by purification steps like distillation and crystallization to yield a high-purity product.

3. What are the advantages of using HEDP in water treatment?

1-Hydroxyethane-1,1-diphosphonic Acid effectively prevents scale and corrosion, remains stable in acidic and alkaline conditions, withstands high temperatures, and is biodegradable, making it ideal for industrial water systems.

4. Is HEDP safe for the environment?

Yes, HEDP Etidronic Acid has low toxicity and is biodegradable, making it an environmentally safer choice for long-term use in water treatment and other industries.

5. Why is HEDP preferred in the textile industry?

1-Hydroxy Ethylidene-1, 1-Diphosphonic Acid prevents scale formation, improves dyeing quality by chelating metal ions, protects equipment from corrosion, and remains stable under high temperature and variable pH conditions in textile processing.
